Agilent Technologies 54830 Series User Manual

Setting Up the Oscilloscope
To inspect options and accessories
1-6
1156A 1.5 GHz Active Probe
1157A 2.5 GHz Active Probe
1158A 4 GHz Active Probe
1159A 1 GHz Differential Probe
1162A 25 MHz, 1:1, 1 M
Ω Passive Probe
1163A 1.5 GHz, 10:1, 500
Ω Passive Probe
1165A 500 MHz, 10:1, 10 M
Ω Passive Probe
10440B 300 MHz, 100:1, 1 MΩ Passive Probe
1250-1454 BNC to Miniature Probe Adapter
E2609E Rackmount Kit
E2614A Wedge Adapter, 0.5 mm spacing, 8 signals
E2615A Wedge Adapter, 0.65 mm spacing, 3 signals
E2615B 2 Wedge Adapters, 0.65 mm spacing, 3 signals6
E2616A Wedge Adapter, 0.65 mm spacing, 8 signals
E2621A 75
Ω terminator
E2622A 100/110/120
Ω differential terminator
E2625A Communication Mask Test Kit Option
E2635A VoiceControl Upgrade Kit
E2643A Wedge Adapter, 0.5 mm spacing, 16 signals
E2644A Wedge Adapter, 0.65 mm spacing, 16 signals
E2645A USB Test Option (for 54831 and 54832 only)
E2646A SQiDD Fixture for USB option
E2654A EZ-Probe® Positioner
E2813A Wedge Adapter, 0.5 mm spacing, 3 signals
E2813B 2 Wedge Adapters, 0.5 mm spacing, 3 signals
E5850A Time Correlation Fixture
(Integrates the Infiniium oscilloscope and the 16700 logic analyzer)
N2771A 30 kV High Voltage Probe
N2845A Upgrades standard memory to 4 Mpts/Ch.
N2846A Upgrades standard memory to 8 Mpts/Ch.
N2847A Upgrades memory from 4 Mpts. to 8 Mpts/Ch.
