Setting Up the Oscilloscope
To connect the digital probe
1-17
To connect the digital probe
1 Push the small connector end of the digital cable with the tab key facing
left into the digital connector.
2 Tighten both thumb screws.
Figure 1-10
Connecting the Digital Cable to the Oscilloscope
The 5483xD Infiniium oscilloscopes are the only oscilloscopes that have 16 digital
channels.
The digital clip lead marked clk (clock) is unused. All the other digital click leads are
used for the digital channels.
