Agilent Technologies 54830 Series User Manual

Using the Oscilloscope
To perform basic user interface operations
3-32
Figure 3-21
Dialog Box Interface Elements
Figure 3-22
Dialog Box with a Drop-Down List Box
Click to put a check mark
in the check box and
enable Connect Dots
mode
Click one of these
radio buttons to
select Minimum,
Variable, or Infinite
persistence
Click on the upward
arrow in this spin box
to increase the
intensity of the grid
Click on the slider
arrow and move it
down to decreaseor
moveit up to increase
the intensity of the
grid
Click and drag the
title bar to move the
dialog box on the
screen
Click one of these
Close buttons to
close the dialog box
...to see the options you can
choose
Click the arrow in a
drop-down list box...
