Using the Oscilloscope
To make a measurement on a waveform
3-53
Figure 3-40
Waveform Measurements
In some cases,
geometric icons
are also
displayed to
associate the
measurement
Channel numbers
associate the
measurement
results with the
channel waveform
being measured.
