Chapter 6: Replacing Assemblies
To remove and replace the AutoProbe assembly
6–8
d Disconnect the mylar flex cable W8 from the AutoProbe board.
See “To disconnect and connect Mylar flex cables” in this chapter.
Figure 5-7
Pushing Out the AutoProbe Faceplate
3 To replace the AutoProbe assembly, reverse the above procedure.
Disconnect mylar
flex cable W8 here
