Agilent Technologies 54853A User Manual

Chapter 6: Replacing Assemblies
To remove and replace the front panel assembly
6–15
10
Remove the two Torx T10 screws that secure the power supply support bracket to the front
panel assembly.
11 Pull the front panel assembly away from the chassis, being careful to feed the ribbon cables
W16 and W20 out through the slot in the front of the chassis and not to damage the backlight
invertor board.
12 To replace the front panel assembly, reverse the above procedure.
Ensure that you observe polarity designations when reconnecting the ribbon cables.
Replacing the BNC hex nuts
When assembling the hex nuts to secure the BNC connectors to the front panel, put the conical side of
the nut toward the front-panel casting.
