Agilent Technologies 54853A User Manual

Chapter 6: Replacing Assemblies
To remove and replace the acquisition board assembly
6–20
Figure 5-20
Removing Cables and Screws
Torx
T10 (4)
Power
Distribution
Board
10 MHz Ref
SMB Cable
Acquisition
Cable W3
Acquisition
Board
Torx T10
(16 in heat
sinks)
Power
Supply
Spring
Cover
Line
Sync Cable
W5
Aux Out
Cable
Probe
Comp
Wire
Torx
T10 (4)
Trig Out
SMB Cable
Aux Trig In
SMB Cable
