Agilent Technologies 54853A User Manual

Chapter 2: Setting Up the Oscilloscope
To connect a printer
2–12
5
Connect the 9-pin “D” connector of the serial printer cable to the serial output port on the
rear panel of the oscilloscope. Tighten the thumbscrews to secure the cable.
Figure 2-12
Attaching the 9-pin “D” Connector
6 Attach the 25-pin “D” connector to the serial input port of the printer. Tighten the
thumbscrews to secure the cable.
Figure 2-13
Attaching the 25-pin “D” Connector
7 Set the printer configuration to use the serial interface. See the documentation for your
printer.
Port on Printer
