Agilent Technologies 54853A User Manual

Chapter 3: Testing Performance
Agilent 54853A/54A/55A Performance Test Record
3–48
DC Measurement Accuracy (Single Cursor) Test
Vertical Sensitivity V
Aux Out
Setting
V
DMM
V
Scope
Max Scope
Error (V
ERR
)
Calculated
Vscope
Lower Limit
(V
DMM –
V
ERR
)
Calculated
Vscope
Upper Limit
(V
DMM
+ V
ERR
)
Channel 1
10 mV/div +30 mV 1.6 mV
20 mV/div +60 mV 3.2 mV
50 mV/div +150 mV 8.0 mV
100 mV/div +300 mV 16.0 mV
200 mV/div +600 mV 32.0 mV
500 mV/div +1.5 V 80.0 mV
1 V/div +2.4 V 160 mV
Channel 2
10 mV/div +30 mV 1.6 mV
20 mV/div +60 mV 3.2 mV
50 mV/div +150 mV 8.0 mV
100 mV/div +300 mV 16.0 mV
200 mV/div +600 mV 32.0 mV
500 mV/div +1.5 V 80.0 mV
1 V/div +2.4 V 160 mV
Channel 3
10 mV/div +30 mV 1.6 mV
20 mV/div +60 mV 3.2 mV
50 mV/div +150 mV 8.0 mV
100 mV/div +300 mV 16.0 mV
200 mV/div +600 mV 32.0 mV
500 mV/div +1.5 V 80.0 mV
1 V/div +2.4 V 160 mV
Channel 4
10 mV/div +30 mV 1.6 mV
20 mV/div +60 mV 3.2 mV
50 mV/div +150 mV 8.0 mV
100 mV/div +300 mV 16.0 mV
200 mV/div +600 mV 32.0 mV
500 mV/div +1.5 V 80.0 mV
1 V/div +2.4 V 160 mV
