Agilent Technologies 5975

104 5975 Series MSD Operation Manual for MassHunter
4 Operating in Chemical Ionization (CI) Mode
WARNING
The GC/MSD interface operates at high temperatures. If you touch it when it is hot,
it will burn you.
Figure 20 The CI GC/MSD interface
Spring-loaded
seal
Reagent gas in
MSD GC oven
Column end protrudes 1 to 2 mm into the ionization chamber.
