Operating in Electron Impact (EI) Mode 3
5975 Series MSD Operation Manual for MassHunter 83
To Remove the MSD Covers
Materials needed
• Screwdriver, Torx T-15 (8710-1622)
If you need to remove one of the MSD covers, follow these procedures
(Figure 14):
To remove the analyzer top cover
Remove the five screws and lift the cover off.
To remove the analyzer window cover
1 Press down on the rounded area on the top of the window.
2 Lift the window forward and off the MSD.
WARNING
Do not remove any other covers. Dangerous voltages are present under other covers.
