CI MSD Hardware Description
Figure 1 is an overview of a typical 5975 GC/MSD system.
The CI hardware allows the 5975 Series MSD to produce high-quality, classical
CI spectra, which include molecular adduct ions. A variety of reagent gases
can be used.
Figure 1 5975 Series GC/MSD system
ALS
7890A GC
CI gas flow module
Local control panel
5975 Series MSD
MSD power switch
GC power switch
