98 5975 Series MSD Operation Manual for MassHunter
3 Operating in Electron Impact (EI) Mode
The MSD can now be stored or moved. The foreline pump cannot be
disconnected; it must be moved with the MSD. Make sure the MSD remains
upright and is never tipped on its side or inverted.
Figure 19 Side plate thumbscrews
Front thumbscrew
Rear thumbscrew
CAUTION
The MSD must remain upright at all times. If you need to ship your MSD to another
location, contact your Agilent Technologies service representative for advice about
packing and shipping.
