Agilent Technologies 5977B Series

Introduction 1
5977B Series MSD Operating Manual 19
MSD Hardware Description
Figure 1 5977B Series GC/MSD system, shown with an Agilent 7890B GC
ALS
7890B GC
7890B GC control panel
5977B Series
MSD
MSD power switch
GC power switch
System status LED
