7 CI Maintenance
202 5977B Series MSD Operating Manual
To Install the CI Source Radiator
Materials needed
• Gloves, clean, lint-free
• Large (8650-0030)
• Small (8650-0029)
• Tweezers (8710-2460)
• T10 Torx screwdriver (5182-3466)
Procedure
1 Align the radiator over the two guide pins on the analyzer support, and
secure it using the two retained screws with a number T10 Torx
screwdriver.
The analyzers, GC/MS interface, and other components in the analyzer chamber
operate at very high temperatures. Do not touch any part until you are sure it is cool.
Always wear clean gloves to prevent contamination when working in the analyzer
chamber.
Make sure you use an antistatic wrist strap and take other antistatic precautions
before touching analyzer components.
When disconnecting leads, pull on the connectors, not on the wires.
