4Operating in EI Mode
88 5977B Series MSD Operating Manual
eModule Mini Display Readout
The eModule mini display, accessible when the analyzer door cover is open,
allows the operator to view the LAN configuration of the instrument including
its IP address, subnet mask, default gateway, and MAC address. This LAN
configuration can be changed using the GC control panel or the web user
interface (WUI) from a web browser.
Front Panel Instrument Status LED
Through the front panel instrument status LED, the operator can view the
current status of the instrument using color codes and LED on/off timing. (See
Table 7.)
Table 7 Front panel Instrument Status LED codes
Instrument status LED code
Ready Solid green
Acquiring data Blinking green (<2 sec)
Not ready Solid yellow
JetClean Acquire & Clean operation Blinking magenta
JetClean Clean Only operation Solid magenta
Ready and not connected to DS Solid blue
Start up (prior to FW load) Blinking red (<2 sec)
Fault Solid red
