General Maintenance 6
5977B Series MSD Operating Manual 195
7 Slide the electron multiplier horn into position.
8 Close the retaining clip.
9 Close the analyzer chamber. (See “To Close the Analyzer Chamber” on
page 196.)
Figure 63 Replacing the EM horn on a Series II Detector
Figure 64 Electron multiplier horn
Retaining clip
Electron multiplier horn
Blue signal wire
