Installation
26
Figure 7. Rear view of GC
Front inlet
Back inlet
Front inlet manifold
Back inlet manifold
Valve for coolant for
Oven cryogenic cooling
Power cord
Cable connections
Front detector manifold
location (shown not
installed; position is covered)
Back detector manifold
location (shown not
installed)
