51
Installation
Step 13. Connecting cables
Table 9. Cabling for Other Instruments in a 6890 System
Instrument 1 Instrument 2 Type of cable Part no.
Mass Selective Detector GC ChemStation GPIB 10833A
7673 GC Automatic
Liquid Sampler
Non-Agilent data system BCD G1530-60630
18594-60520
7673 GC Automatic
Liquid Sampler
3395A Integrator
3396B Integrator
BCD 03396-60560
7673 GC Automatic
Liquid Sampler
3395B Integrator
3396C Integrator
BCD 03396-60560
7673 GC Automatic
Liquid Sampler
35900 C/D/E
A/D Converter
BCD 35900-60850
GC ChemStation Modem RS-232 24540-80012, or
G1530-61120
7694 Headspace
Sampler
GC ChemStation RS-232, 9-pin female/
9-pin male
24542U
7694 Headspace
Sampler
INET Integrator RS-232, 15-pin male/
9-pin female
03396-60530
7694 Headspace
Sampler
Non-INET Integrator RS-232, 15-pin male/
9-pin female
03396-60530
7694 Headspace
Sampler
Unspecified, non-Agilent
instrument
Binary-coded decimal
cable
03396-60570
Splitter ("Y") cable for
APG remote
G1530-61200
