Installation
Step 13. Connecting cables
50
Table 8. Cabling Requirements
Instrument Connected to Required Cable(s) Part no.
7683 Automatic Liquid Sampler Injector cable is integral tray cable G2614-60610
7673 Automatic Liquid Sampler RS 232, 9-pin female/9-pin male
Remote, 2-m 9-pin male/9-pin female
G1530-60600
G1530-60930
GC ChemStation GPIB, 2 m 10833B
7694 Headspace
Sampler
Remote, 9-pin male/6-pin connector G1290-60570
7695 Purge and Trap
Sampler
Remote, 25-pin male/9-pin male G1500-60820
IN E T I nt eg ra to r. Us e t wo ca bl es fo r a n
INET loop
Two 5-m INET cables 82167-60003
3395A Integrator Remote, 9 pin/15 pin
Analog, 2 m, 6 pin
03396-61020
G1530-60570
3395B Integrator Remote, 9 pin/15 pin
Analog, 2 m, 6 pin
03396-61010
G1530-60570
3396B Integrator Remote, 9 pin/15 pin
Analog, 2 m, 6 pin
03396-61020
G1530-60570
3396C/3397 Integrator Remote, 9 pin/15 pin
Analog, 2 m, 6 pin
03396-61010
G1530-60570
Non-Agilent Integrator Analog, 2 m, 6 pin G1530-60560
35900 C/D/E A/D Converter Remote, 9-pin male/9-pin male
Analog, 2 m, 6 pin
G1530-60930
G1530-60570
Mass Selective Detector Remote, 2-m, 9-pin male/9-pin male G1530-60930
Modem Modem, 9-pin female/9-pin male, or
Modem, 9-pin female/25-pin male
G1530-61120, or
24540-80012
Non-Agilent
data system
General use remote,
9-pin male/spade lugs
External event, 8-pin/spade lugs
35900-60670 (2 m),
35900-60920 (5 m),
35900-60930 (0.5 m)
G1530-60590
Non-Agilent
instrument, unspecified
External event, 8 pin/spade lugs G1530-60590
Stream selection valves
Gas sampling valves
See documentation accompanying the
valve
LAN Ether Twist 4 pair 92268B
