49
Installation
Step 13. Connecting cables
Figure 23. GC—networked GC ChemStation—GC Automatic Liquid
Sampler
Number Part no. and description
1 G1530-60600, RS-232 cable, 9-pin female/9-pin female
2 G1530-60930, Remote start/stop cable, 2-m, 9-pin male/9-pin male
3 92268 B, LAN cable, Ether twist 4 pair
GC
(with 7683 ALS
if used)*
7673 ALS
(if used)
1 RS-232
2 APG remote
Networked
GC ChemStation
3 LAN cable
* The 7683 controller is internal to the 6890 Plus GC. The G2613A Injector and the 2614
tray plug directly into the GC.
