102 708-DS / 709-DS Operator’s Manual
4 Operating the 708-DS / 709-DS
Dialog Screens (Green / Blue)
Table 1 5 Dialog Screens (Green / Blue)
Delayed Start Dialog
The Delayed Start screen displays when a delayed start time has been
entered (“Method - Start Options” on page 52). The date and time when
the method starts is displayed on the screen. Access to the remainder of
the instrument functions is prohibited until the method has finished.
Press Cancel to stop the loaded method and return to the Main screen.
Delayed Start Date / Time Dialog
Displays when Time Delayed Start has been selected (“Method - Start
Options” on page 52). Press the box beside either the Date or Time
prompts to display the Numeric and Date and Time Entry screen
(“Numeric and Time / Date Entry” on page 97). Press Cancel to abort
the process and return to the previous screen.
Method Completion
The Method Completion screen displays when a method has completed.
The total elapsed time, current date, and time the method completed is
displayed. Press Ok to return to the Main screen.
Time Point Approaching
Displays when a sample point is approaching (“Method Properties
Screen 4” on page 74). The time to the next sample point is indicated on
the screen. Press Ok to clear the dialog and return to the Main screen. If
no action is taken, this screen clears itself when 0 seconds is reached.
