Operating the 708-DS / 709-DS 4
708-DS / 709-DS Operator’s Manual 97
Numeric and Time / Date Entry
This screen is a specialized subset of the alphanumeric data entry
screen. It has been optimized for numeric, date, and time data entry. As
keys are pressed, they display in the upper box of the display. The valid
data entry range and the previous data entry will be shown just below
the display. The maximum valid data string length is 25 characters.
Special function keys are defined below:
From the Numeric and Time / Date Entry screen:
• Press Ok to return to the previous window. The data entered is
returned and placed in the appropriate data entry box.
Table 1 3 Numeric and Time / Date Entry
Option Function
Backspaces and deletes one character every time it is pressed.
/ Used as separator in date entries.
: Used as separator in time entries.
AM Designates morning when entering time in 12-hr format.
PM Designates afternoon when entering time in 12-hr format.
