About the Packed Column Inlet
This inlet is used with packed columns when high-efficiency
separations are not required.
The inlet is flow controlled regardless of whether the column is
defined or not.
This inlet is available in EPR (electronic pneumatics regulation)
equipped GCs only.
Valve
Frit
EPR Module
Inlet Weldment
FS = Flow Sensor
FS
Carrier Supply
80 PSI
Column
