Chapter 4 193
Key Function Descriptions
Key Function Tables
PLOT TRACE A CONFIG
Plots only the contents of trace A and any markers
associated with the trace. To halt plotting before it is
complete, press STOP TRACE A.
PLOT TRACE B CONFIG
Plots only the contents of trace B and any markers
associated with the trace. To halt plotting before it is
complete, press STOP TRACE B.
PLOTTER ADDRESS CONFIG
Displays the GPIB address of the plotter. After
changing and entering the address, press STORE
GPIB ADR.
PLOTTER CONFIG CONFIG
Accesses a menu for configuring a plotter as a
hard-copy device.
POSITIVE BIAS AUX CTRL
Selects positive mixer bias for an external mixer. When
this function is selected, a "+" appears on the left side
of the display. Not available with an 8560E/EC Option
002.
POSTSCLR CAL
Displays the value of the post scaler divider within the
fractional N assembly.
POWER MENU MEAS/USER
Accesses the power measurements including occupied
power bandwidth, channel power and carrier power.
POWER ON RECALL
Sets the instrument state to the state stored in the
power-on register.
PRESEL AUTO PK AUX CTRL
Automatically peaks the preselector for the selected
signal on a trace.
PRESEL MAN ADJ AUX CTRL
Permits manual adjustment of the preselector. Peak
the preselector using the data keys, the step keys, or
the knob.
PRESEL PEAK AUX CTRL
Displays a menu of functions for preselected external
mixers.
PRESET —
Sets the spectrum analyzer to the preset state.
PRINTER ADDRESS CONFIG
Displays the GPIB address of the printer. After
changing the address, press STORE HPIB ADR.
PRINTER CONFIG CONFIG
Accesses a menu for configuring a printer as a
hard-copy device.
PURGE CORR CAL
Allows you to purge all of the ampcor correction points
that are in active memory.
PWR MENU HELP MEAS/USER
Includes measurement information for making
occupied power bandwidth, channel power, carrier
power, and adjacent channel power measurements.
Table 4-2 Instrument State Functions
Instrument State
Keys
Access Key
Description
