Agilent Technologies 89410A Service Guide

3-6
Replacing Assemblies
What to do after replacing an assembly
Assembly Replaced Adjustment Performance Test
A10 Analog Input , channel 1 Input flatness, page 2-10-
Input capacitance, page 2-13-
Input offset, page2-16
Anti-alias filter, page 2-18
Calibrator, page 2-37
Amplitude accuracy
Amp_phase match (option AY7 only)
Input trigger
Harmonic distortion
Input capacitance
DC offset
Spurious signals
Noise
A10 Analog Input, channel 2 Input flatness, page 2-10
Input capacitance, page 2-13-
Input offset, page2-16-
Anti-alias filter, page 2-18
Amplitude accuracy
Amp_phase match (option AY7 only)
Input trigger
Harmonic distortion
Input capacitance
DC offset
Spurious signals
Noise
A11 Front Panel Connector
A12 Rear Panel Connector
A21 A/D Converter, channel 1 ADC, page 2-24-
Calibrator, page 2-37
Amplitude accuracy
Amp_phase match (option AY7 only)
Harmonic distortion
DC offset
Spurious signals
Noise
A21 A/D Converter, channel 2 ADC, page 2-24 Amplitude accuracy
Amp_phase match (option AY7 only)
Harmonic distortion
DC offset
Spurious signals
Noise
A30 Digital Source
A35 Analog Source 10 MHz low pass filter, page 2-25
Calibrator, page 2-37
Amplitude accuracy
Source amplitude accuracy
Source distortion
A36 Trigger Autorange detect level, page 2-29 Amp_phase match
Input trigger
External trigger
External arm
A40 CPU Calibrator, page 2-37
A42 Memory
A43 Expanded Memory
A47 DSP/Display Controller
A50 Digital Filter
A55 Sample RAM
A56 Expanded Sample RAM
