Agilent Technologies 89410A Service Guide

3-15
Replacing Assemblies
To remove disk drive
5
Using a T-15 torx driver, remove the two screws from the
disk drive bracket.
6
Using a T-15 torx driver, remove the screw from the side
strut.
7
Note the polarity of the disk drive cable (the cable is not
keyed to the Disk Drive assembly and can be incorrectly
connected). Disconnect the disk drive cable from the Disk
Drive assembly. Carefully guide the Disk Drive assembly,
dust cover, and bracket out the front.
8
Using a T-10 torx driver, remove the four screws from the
disk drive bracket.
