Agilent Technologies 89410A Installation And Verification

Self Test
Measurement Lower Limit Upper Limit Measured Value Pass/Fail
Long Confidence
Frequency Accuracy
Measurement Lower Limit
(MHz)
Upper Limit
(MHz)
Measured Value
(MHz)
Pass/Fail
Accuracy at 9 MHz
Amplitude Accuracy
Measurement Lower Limit
(dBm)
Upper Limit
(dBm)
Measured Value
(dBm)
Pass/Fail
9.876 MHz, −18 dBm, Ch 1, 50 ohm
−0.5
0.5
9.876 MHz, 6 dBm, Ch 1, 50 ohm
−0.5
0.5
9.876 MHz, −18 dBm, Ch 1, 1 Mohm
−0.5
0.5
9.876 MHz, 6 dBm, Ch 1, 1 Mohm
−0.5
0.5
9.876 MHz, −18 dBm, Ch 2, 50 ohm †
−0.5
0.5
9.876 MHz, 6 dBm, Ch 2, 50 ohm †
−0.5
0.5
9.876 MHz, −18 dBm, Ch 2, 1 Mohm †
−0.5
0.5
9.876 MHz, 6 dBm, Ch 2, 1 Mohm †
−0.5
0.5
49.234 kHz, −18 dBm, Ch 1, 50 ohm
−0.5
0.5
49.234 kHz, 6 dBm, Ch 1, 50 ohm
−0.5
0.5
49.234 kHz, −18 dBm, Ch 1, 1 Mohm
−0.5
0.5
49.234 kHz, 6 dBm, Ch 1, 1 Mohm
−0.5
0.5
49.234 kHz, −18 dBm, Ch 2, 50 ohm †
−0.5
0.5
49.234 kHz, 6 dBm, Ch 2, 50 ohm †
−0.5
0.5
49.234 kHz, −18 dBm, Ch 2, 1 Mohm †
−0.5
0.5
49.234 kHz, 6 dBm, Ch 2, 1 Mohm †
−0.5
0.5
† Option AY7 only
Serial Number:______________________Report Number:____________________
Verifying Specifications Agilent 89410A
Operation Verification Test Record
2of8
