Agilent Technologies 89410A Installation And Verification

Amp_Phase Match (Option AY7 only)
Measurement Lower Limit Upper Limit Measured Value Pass/Fail
−30 dBm Magnitude
−0.25 dB
0.25 dB
−30 dBm Phase
−2deg
2deg
−22 dBm Magnitude
−0.25 dB
0.25 dB
−22 dBm Phase
−2deg
2deg
−14 dBm Magnitude
−0.25 dB
0.25 dB
−14 dBm Phase
−2deg
2deg
−6 dBm Magnitude
−0.25 dB
0.25 dB
−6dBmPhase
−2deg
2deg
2 dBm Magnitude
−0.25 dB
0.25 dB
2dBmPhase
−2deg
2deg
10 dBm Magnitude
−0.25 dB
0.25 dB
10 dBm Phase
−2deg
2deg
Input Coupling
Measurement Lower Limit Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
dc − ac, Ch 1
3
dc − ac, Ch 2 †
3
† Option AY7 only
Serial Number:______________________Report Number:____________________
Agilent 89410A Verifying Specifications
Operation Verification Test Record
3of8
