Input Trigger
Measurement Lower Limit
(V)
Upper Limit
(V)
Measured Value
(V)
Pass/Fail
Channel 1, +2 Volt, Slope Negative
1.368 2.632
Channel 1, −2 Volt, Slope Positive
−2.632 −1.368
Channel 2, +2 Volt, Slope Negative †
1.368 2.632
Channel 2, −2 Volt, Slope Positive †
−2.632 −1.368
† Option AY7 only
External Trigger
Measurement Lower Limit
(V)
Upper Limit
(V)
Measured Value
(V)
Pass/Fail
+5 Volt, Slope Negative
4.5 5.5
−5 Volt, Slope Positive
−5.5 −4.5
External Arm
Measurement Lower Limit
(V)
Upper Limit
(V)
Measured Value
(V)
Pass/Fail
+2 Volt, Region Above
1.5 2.5
−2 Volt, Region Below
−2.5 −1.5
Serial Number:______________________Report Number:____________________
Verifying Specifications Agilent 89410A
Operation Verification Test Record
4of8
