Equipment Configuration Menu Descriptions
Press [
EQUIP CONFIG
] to display the test equipment
configuration and the following softkeys:
[
SYNTHESIZER
]
Prompts you to enter the model, serial number,
HP-IB address, and calibration due date for the
frequency synthersizer.
If you select [
OTHER
] for model, the program
prompts you to type in a model, serial number, and
calibration due date but not an HP-IB address.
When entering the calibration due date, only four
characters are displayed on the screen. However,
you can enter up to nine characters and they will
be printed.
[
SYNTH/LVL GEN
]
Prompts you to enter the model, serial number,
HP-IB address, and calibration due date for the
synthesizer/level generator.
[
ANALYZER
]
Prompts you to enter the model, serial number,
HP-IB address, and calibration due date for the
spectrum analyzer.
[
MULTIMETER
]
Prompts you to enter the model, serial number,
HP-IB address, and calibration due date for the
digital multimeter.
[more]
Displays the next page.
[
STEP_ATT 1DB
]
Prompts you to enter the model, serial number,
calibration due date, and calibration data for the
1 dB step attenuator.
[
STEP_ATT 10DB
]
Prompts you to enter the model, serial number,
calibration due date, and calibration data for the
10 dB step attenuator.
[mW_POWER METER]
Prompts you to enter the model, serial number, and
calibration due date for the milliwatt power meter.
[
SAVE SETUP
]
Saves the current equipment configuration to a file
for future recall.
[
RECALL SETUP
]
Recalls an equipment configuration that was
previously saved using [
SAVE SETUP
].
[
RETURN
]
Returns to the ITM_89410A main menu.
Agilent 89410A Verifying Specifications
2-49
