Test Configuration Menu Descriptions
Press [
TEST CONFIG
] to display the test
configuration and the following softkeys:
[
HP 89410A ADDRESS
]
Prompts you to enter the HP-IB address for the
HP 89410A DC-10 MHz Vector Signal Analyzer.
The HP-IB address equals 100
× (interface select
code) + (primary address). The interface select
code for the printer and test equipment is 7 (for
example, if the primary address is 8, the HP-IB
address is 708).
[
PRINTER ADDRESS
]
Prompts you to enter the HP-IB address for the
printer. To disable the printer, set the printer
address to 0.
[
PROCEDURE
]
Prompts you to select the operation verification
procedure (OP_VERIFY) or the performance test
procedure (PERFORMAN).
[
STOP AFTER
]
Prompts you to select stop after limit failure, stop
after each measurement, or do not stop after a
limit failure or measurement. If [
Limit Failure
]is
selected, the program stops after the failing
measurement is displayed but before it is printed.
At this point you can continue on and print the
failing measurement or restart the measurement.
[
BEEPER
]
Toggles the beeper on and off. When the beeper is
on, the program beeps approximately every 2
minutes while waiting for you to follow the
directions on the display and press [
CONTINUE
].
[
RETURN
]
Returns to the ITM_89410A main menu.
Verifying Specifications Agilent 89410A
2-48
