Agilent InfinityLab LC Series Vialsamplers User Manual 318
11 Hardware Information
Electrical Connections
Rear View of the Module
Figure 52 Rear view of Vialsampler - electrical connections and label
Serial Number Information
The serial number information on the instrument labels provide the following
information:
Configuration switch
Power socket
CAN
ERI
LAN
USB-Mini-Port
CCXZZ00000 Format
CC Country of manufacturing
• DE = Germany
• JP = Japan
• CN = China
X Alphabetic character A-Z (used by manufacturing)
ZZ Alpha-numeric code 0-9, A-Z, where each combination unambig-
uously denotes a module (there can be more than one code for
the same module)
00000 Serial number
