Agilent InfinityLab LC Series Vialsamplers User Manual 96
3Using the Module
Using the Optional Integrated Column Compartment
Using the Optional Integrated Column
Compartment
The following section describes how to operate the Agilent Integrated Column
Compartment.
Dashboard
When the Integrated Column Compartment (ICC) is installed in a Vialsampler and
configured in the chromatography data system (CDS), a new tile appears on the
dashboard, comprising a standalone graphical user interface (GUI) for the ICC.
1
2
3
4
5
6
7
8
1 ICC: Turn On/Off
2 ICC: Heater Status (On/Off)
3 ICC: Actual Temperature
4 ICC: Set Temperature
5 ICC: Column Information
6 ICC: Status Indicator
7 ICC: Early Maintenance Feedback (EMF) Status
8 ICC: Column Identification Tag Recognised
