Agilent InfinityLab LC Series Vialsamplers User Manual 60
3Using the Module
Vial Drawers and Trays
Drawer for 50 x 2 mL Vials Classic Right: Vial 51-100
External Tray 5-position: 201 – 205 Position
(The disposal tube is installed into the external tray by turning and pushing it into
the backside of the hole position, No. 206)
Figure 14 Numbering of drawer position (left-hand Drawer for 66 x 2 mL Vials)
Figure 15 Numbering of drawer position (right-hand Drawer for 66 x 2 mL Vials)
Figure 16 Numbering of drawer position (left-hand Drawer for 18 x 6 mL Vials)
Figure 17 Numbering of drawer position (right-hand Drawer for 18 x 6 mL Vials)
