Agilent InfinityLab LC Series Vialsamplers User Manual 81
3Using the Module
Install the Optional Integrated Column Compartment
11 Mount the column in the column holder clip(s). 12 Route the capillary coming from the column through the
opening between the flap door and the ICC body
towards the detector module.
Alternatively, the capillary can also be routed through the
incisions at the right side of the ICC dedicated for this pur
-
pose.
13 Close the flap door until the latch is locked. 14 Close the doors.
15 Turn on the sampler and the pump.
