8CI Maintenance
To Install the CI Source Radiator
5977B Series MSD Operating Manual 227
To Install the CI Source Radiator
Materials needed
• Gloves, clean, lint-free
• Large (8650-0030)
• Small (8650-0029)
• Tweezers (8710-2460)
• T10 Torx screwdriver (5182-3466)
Procedure
1 Align the radiator over the two guide pins on the analyzer support, and secure
it using the two retained screws with a number T10 Torx screwdriver.
The analyzers, GC/MSD interface, and other components in the analyzer
chamber operate at very high temperatures. Do not touch any part until you
are sure it is cool.
Always wear clean gloves to prevent contamination when working in the
analyzer chamber.
Make sure you use an antistatic wrist strap and take other antistatic
precautions before touching analyzer components.
When disconnecting leads, pull on the connectors, not on the wires.
