5-8 Service Guide N5230-90024
Theory of Operation PNA Series Microwave Network Analyzers
Synthesized Source Group Operation N5230C
Table 5-2 Subsweep Frequencies
Band
Mix Brick
L.O.
Harmonic
Number
A7 Frac-N
Synthesizer
Frequency (GHz)
A6
Multiplier
Frequency (GHz)
A9 Frac-N
Synthesizer
Frequency (GHz)
A8
Multiplier
Frequency (GHz)
A17/A19
MASS
Frequency (GHz)
1 1 0.010 to 0.045 0.010 to 0.045 0.010 to 0.045 0.010 to 0.045 0.010 to 0.045
2 1 0.045 to 0.748 0.045 to 0.748 0.045 to 0.748 0.045 to 0.748 0.045 to 0.748
3 1 0.748 to 1.500 0.748 to 1.500 0.748 to 1.500 0.748 to 1.500 0.748 to 1.500
4 1 1.500 to 3.125 1.500 to 3.125 1.500 to 3.125 1.500 to 3.125 1.500 to 3.125
5 1 1.563 to 2.083 3.125 to 4.167 1.563 to 2.083 3.125 to 4.167 3.125 to 4.167
6 1 2.083 to 2.625 4.167 to 5.250 2.083 to 2.625 4.167 to 5.250 4.167 to 5.250
7 1 2.625 to 3.125 5.250 to 6.250 2.625 to 3.125 5.250 to 6.250 5.250 to 6.250
8 1 1.563 to 1.969 6.250 to 7.875 1.563 to 1.969 3.125 to 3.938 6.250 to 7.875
9 1 1.969 to 2.083 7.875 to 8.333 1.969 to 2.083 3.938 to 4.167 7.875 to 8.333
10 1 2.083 to 2.344 8.333 to 9.375 2.083 to 2.344 4.167 to 4.688 8.333 to 9.375
11 3 1.563 to 1.750 3.125 to 3.500 2.344 to 2.625 4.688 to 5.250 9.375 to 10.500
12 3 1.750 to 2.083 3.500 to 4.167 2.625 to 3.125 5.250 to 6.250 10.500 to 12.500
13 3 2.083 to 2.625 4.167 to 5.250 1.563 to 1.969 3.125 to 3.938 12.500 to 15.750
14 3 2.625 to 2.778 5.250 to 5.556 1.969 to 2.083 3.938 to 4.167 15.750 to 16.667
15 3 2.778 to 3.125 5.556 to 6.250 2.083 to 2.344 4.167 to 4.688 16.667 to 18.750
16 3 1.563 to 1.750 6.250 to 7.000 2.344 to 2.625 4.688 to 5.250 18.750 to 21.000
17 3 1.750 to 1.875 7.000 to 7.500 2.625 to 2.813 5.250 to 5.625 21.000 to 22.500
18 3 1.875 to 2.083 7.500 to 8.333 2.813 to 3.125 5.625 to 6.250 22.500 to 25.000
19 3 2.083 to 2.188 8.333 to 8.750 1.563 to 1.641 3.125 to 3.281 25.000 to 26.250
20 3 2.188 to 2.208 8.750 to 8.833 1.641 to 1.656 3.281 to 3.313 26.250 to 26.500
21 3 2.208 to 2.383 8.833 to 9.533 1.656 to 1.788 3.313 to 3.575 26.500 to 28.600
22 5 2.860 to 3.125 5.720 to 6.250 1.788 to 1.953 3.575 to 3.906 28.600 to 31.250
23 5 1.563 to 1.575 6.250 to 6.300 1.953 to 1.969 3.906 to 3.938 31.250 to 31.500
24 5 1.575 to 1.667 6.300 to 6.667 1.969 to 2.083 3.938 to 4.167 31.500 to 33.333
25 5 1.667 to 1.850 6.667 to 7.400 2.083 to 2.313 4.167 to 4.625 33.333 to 37.000
26 5 1.850 to 2.025 7.400 to 8.100 2.313 to 2.531 4.625 to 5.063 37.000 to 40.500
27 5 2.025 to 2.083 8.100 to 8.333 2.531 to 2.604 5.063 to 5.208 40.500 to 41.667
28 5 2.083 to 2.100 8.333 to 8.400 2.604 to 2.625 5.208 to 5.250 41.667 to 42.000
29 5 2.100 to 2.340 8.400 to 9.360 2.625 to 2.925 5.250 to 5.850 42.000 to 46.800
30 5 2.340 to 2.500 9.360 to 10.000 2.925 to 3.125 5.850 to 6.250 46.800 to 50.000
