Agilent Technologies N5230C User Manual

Service Guide N5230-90024 4-13
PNA Series Microwave Network Analyzers Troubleshooting
N5230C Front Panel Troubleshooting
Front Panel Keypad and RPG Test
Test the front panel keypad by running the front panel test. To run the front panel test, perform the following:
Press UTILITY , then , then , then .
A
Front Panel Key Test Utility dialog box will be displayed, as shown in Figure 4-4.
Figure 4-4 Front Panel Key Test Utility Dialog Box
System
Service
More
Front Panel Test
