7-16 Service Guide N5230-90024
Repair and Replacement Procedures PNA Series Microwave Network Analyzers
Removing and Replacing the A5 through A10 Boards and the Plenum Bracket N5230C
Removing and Replacing the A5 through A10 Boards
and the Plenum Bracket
Tools Required
• T-10 TORX driver (set to 9 in-lb)
• T-20 TORX driver (set to 21 in-lb)
• ESD grounding wrist strap
Removal Procedure
Refer to Figure 7-6 for this procedure.
1. Disconnect the power cord.
2. Remove the outer and inner covers. Refer to “Removing the Covers” on page 7-6.
3. With a T-10 TORX driver, remove the cable hold down wire used to secure cables to the top of the
midweb by removing the attachment screw (item
①
).
4. Remove any or all of the A5 through A10 boards:
a. Identify the board you want to remove and disconnect any cables that are attached to it.
NOTE Before removing the board completely, check the bottom of the board for any attached
cables and disconnect them.
b. While holding on to the extractors (item
➁), slide the board out of the slot and remove it from the
analyzer.
5. Remove the plenum bracket:
a. Remove the remaining screw (item
③
) holding the plenum bracket in place. The other screw (item
①
), that also attaches the cable hold down wire, was already removed.
b. Remove the plenum bracket from the analyzer.
Replacement Procedure
1. Reverse the order of the removal procedure. When reinstalling the cable hold down wire, be sure that all
cables are positioned so that they will not be pinched.
2. Perform the post-repair adjustments, verifications, and performance tests that pertain to this removal
procedure. Refer to Table 7-2 on page 7-54.
