6-16 Service Guide N5230-90024
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230C
Bottom Assemblies, Option 220
Reference
Designator
Part Number
a
a. Part numbers in italic typeface are for rebuilt exchange assemblies. Refer to “Rebuilt-Exchange Assemblies” on page 6-5.
Qty Description
A16 E8364-60181 1 Test set motherboard
A17
5087-7281
5087-6281
1 MASS 26.5
A20
5087-7830
5087-6830
Was 5087-7277
1 Mixer brick
A21
A22
5087-7716 2
Test port 1 bridge coupler
Test port 2 bridge coupler
A41 Hard disk drive. Refer to “Hard Disk Drive Assembly, All Options” on page 6-42.
➀
E8361-60059
1
USB hub board
To Next Page
