6-8 Service Guide N5230-90024
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230C
Front Panel Assembly, Front Side, All Options
Reference
Designator
Part Number Qty Description
➀
a
a. When ordering a replacement front frame assembly, you must also order items
➁
,
➄
, and
➇
.
N5230-20225
Was N5230-20125
1Front frame
➁
N5230-80028
Was N5230-80018
b
b. Use keyboard overlay part number N5230-80018 with the following models and serial numbers:
* E8362C: MY48120116 and below; SG48120102 and below.
* E8362CH85: MY48150106 and below; SG48150101 and below.
* E8363C: MY48130162 and below; SG48130102 and below.
* E8363CH85: MY48150101.
* E8364C: MY48140153.
* E8364CH85: MY48150101.
1 Keypad overlay
➂
c
c. For part numbers of rack mount kits and handle kits, refer to “Rack Mount Kits and Handle Kits” on page 6-48.
5041-9183 2 With handles—front handle side trim
5041-9174 2 Without handles—trim strip, filler
➃
N5230-00016 1 Lower front dress panel
➄
E8364-80002
1
Front panel overlay; Option 420 or Option 520
N5230-80017 Front panel overlay; Option 220
N5230-80005 Front panel overlay; Option 225, Option 425, or Option 525
➅
0515-4791 10 Machine screw, M3.0 x 4 flat head
➆
W1312-40017 1 Front knob
➇
N5230-80022
1
Nameplate, N5230C 10 MHz to 20 GHz
N5230-80023 Nameplate, N5230C 10 MHz to 40 GHz
N5230-80024 Nameplate, N5230C 10 MHz to 50 GHz
