Agilent Technologies N5230C User Manual

6-14 Service Guide N5230-90024
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230C
Top Cables, All Options
Reference
Designator
Ty p e
a
a. SR = semirigid coaxial cable; F = flexible coaxial cable; nR = n wires in a ribbon (flat) cable; nW = n wires in a wrapped cable
Part Number Qty Description
W1
SR N5230-20041
1
A7 fractional-N synthesizer board J106
to A6 multiplier board
W2 1
A7 fractional-N synthesizer board J101
to A6 multiplier board
W3 SR
N5230-20009 1
A6 multiplier board to A20 mixer brick (For Option 220 and 225
analyzers.)
N5230-20043 1
A6 multiplier board to A20 mixer brick (For Option 420, 425, 520,
and 525 analyzers.)
W4
SR N5230-20041
1 A9 fractional-N synthesizer board J106 to A8 multiplier board
W5 1
A9 fractional-N synthesizer board J101
to A8 multiplier board
W6 SR
N5230-20010 1
A8 multiplier board to A17 MASS 26.5 (For Option 220 and 225
analyzers.)
N5230-20044 1
A8 multiplier board to A18 MA26.5 (For Option 420, 425, 520,
and 525 analyzers.)
W21 F N5230-60006 1 A20 mixer brick to A5 SPAM board J3
W22 F N5230-60007 1 A20 mixer brick to A5 SPAM board J4
W23 F N5230-60008 1 A20 mixer brick to A5 SPAM board J5
W24 F N5230-60009 1 A20 mixer brick to A5 SPAM board J6
W25
F 8120-5055
1
Rear-panel 10 MHz REF. IN
to A10 frequency reference board J2
W26 1
A10 frequency reference board J3
to rear-panel 10 MHz REF. OUT
W27 F N5230-60010 1
A10 frequency reference board J10
to A7 fractional-N synthesizer board J105
W28 F N5230-60011 1
A10 frequency reference board J11
to A9 fractional-N synthesizer board J105
➀
40R 8121-0116 1
A3 front panel interface board
to A14 system motherboard
➁
50R 8121-0817 1
A41 hard disk drive assembly
to A15 CPU board
