6-2 Service Guide N5230-90024
Replaceable Parts PNA Series Microwave Network Analyzers
Information in This Chapter N5230C
Information in This Chapter
This chapter:
• identifies the replaceable parts for the Agilent PNA series microwave network analyzer.
• includes several tables and illustrations to assist you in identifying the correct part for your analyzer.
• contains ordering information for new assemblies and rebuilt-exchange assemblies.
Chapter Six at-a-Glance
Section Title Summary of Content Start Page
Ordering Information How to order a replaceable part from Agilent
Te ch nol ogi es .
Page 6-3
Assembly Replacement Sequence The correct sequence for replacing a defective assembly. Page 6-4
Rebuilt-Exchange Assemblies
The definition of a rebuilt-exchange assembly.
The procedure for replacing and returning a defective
assembly to Agilent Technologies.
Page 6-5
Replaceable Parts Listings
A table that lists the location of the assemblies in your
analyzer by reference designator.
A table that provides the location of the replaceable parts
in your analyzer by type of part:
• Assemblies (front panel, top, and bottom)
• Cables (top and bottom)
• Hardware (internal, hard disk drive, rear panel, and
external)
• Miscellaneous replaceable parts
Page 6-6
