6-12 Service Guide N5230-90024
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230C
Top Assemblies, All Options
Reference
Designator
Part Number
a
a. Part numbers in italic typeface are for rebuilt exchange assemblies. Refer to “Rebuilt-Exchange Assemblies” on page 6-5.
Qty Description
A4 0950-4599 1 Power supply assembly
A5 E8356-60194 1 Signal processing ADC module (SPAM) board
A6, A8 E8364-60182 2 Multiplier board
A7, A9 E8364-60189 2 Fractional-N synthesizer board
A10 E8364-60136 1 Frequency reference board
A14 N5230-60023 1 System motherboard
A15 E8364-60026 1 1.1 GHz CPU Board
B1 Fans
Refer to “Internal Hardware and Miscellaneous Parts, All Options” on
page 6-36.
