6-34 Service Guide N5230-90024
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230C
Bottom Hardware and Miscellaneous Parts, All Options
Reference
Designator
Part Number Description
➀
E8361-60059 USB hub board
➁
0515-1934
Machine screw M2.5 x 6 (USB hub board
➀
)
➂
0515-0430
Machine screw M3.0 x 6 pan head (front panel LED board
➆
, A17, A19–A20,
attenuator bracket
➅
)
➃
0515-0374 Machine screw M3.0 x 10 pan head (A18)
➄
0515-0372 Machine screw M3.0 x 8 pan head (A25, A26)
➅
E8364-00002 Bracket, attenuator
➆
08720-60182 Front-panel LED board
➇
0515-0664 Machine screw M3.0 x 12 pan head (A16)
➈
E8364-00007 Hard disk drive shield, stationary bracket
To Next Page
