Service Guide N5230-90024 2-7
PNA Series Microwave Network Analyzers General Product Information
N5230C Required Service Test Equipment
Required Service Test Equipment
Equipment Critical Specifications
Recommended
Model or Part
Number
Alternate
Model or Part
Number
Use
a
a. P = Performance tests, A = Adjustments, T = Troubleshooting, V = System verification
Test Instruments and Software
Frequency counter
Freq: 10 MHz to 10.5 GHz
Accuracy : 0.5 ppm
53151A
Opt 001
None P, A, T
Spectrum analyzer
Min Freq: 1 MHz
Max Freq: > 4 GHz
Resolution BW: 300 Hz
8565E
856xE A, T
Power meter Accuracy: 0.0068 dB E4418B/19B
E4418A/19A
b
b. If an accurate measurement of the dynamic accuracy specification is not required, the E4418A or E4419A can be
used.
P, A, T
Power sensor
Freq: 10 MHz to 3.0 GHz
Range: –30 to +20 dBm
8482A
None
P, A, T
Power sensor
Freq: 3.0 GHz to 50 GHz
Range: –30 to +20 dBm
8487A
None
P, A, T
Dynamic accuracy
test set
None specified
U3020AD01
None P
Digital multi-meter
Voltage and resistance
measurement capability
Voltage resolution: 10 mV
Any Any T
Printer N/A
Any printer with Microsoft Windows
2000 driver
P
Test soft ware
c
c. The recommended model or part number for all equipment listed with a “P” in the Use column is required for proper
operation of this test software.
N/A N7840A None P
