6-26 Service Guide N5230-90024
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230C
Bottom Cables, Options 420 and 520
Reference
Designator
Typ e
a
a. SR = semirigid coaxial cable; F = flexible coaxial cable; nR = n wires in a ribbon (flat) cable; nW = n wires in a wrapped cable
Part Number Qty Description
W3, W6 SR Refer to “Top Cables, All Options” on page 6-14.
W7 SR N5230-20033 1 A18 MA 26.5 to A19 MASS 50
W8 SR N5230-20027 1 A19 MASS 50 to A21 test port 1 coupler
W9 SR N5230-20026 1 A19 MASS 50 to A22 test port 2 coupler
W10 SR N5230-20028 1 A19 MASS 50 to A20 mixer brick (R1)
W11 SR N5230-20025 1 A19 MASS 50 to A20 mixer brick (R2)
W12 SR N5230-20029 1 A21 test port 1 coupler to A20 mixer brick (A)
W13 SR N5230-20024 1 A22 test port 2coupler to A20 mixer brick (B)
W21-W24 F Refer to “Top Cables, All Options” on page 6-14.
W29 F N5230-60004 1 A19 MASS 50 J2 to A16 test set motherboard J205 (R2)
W30 F N5230-60003 1 A19 MASS 50 J1 to A16 test set motherboard J204 (R1)
W31 F N5230-60005 1
A19 MASS 50 J3
to A16 test set motherboard J206 (MASS)
➀
100R 8121-0118 1
A14 system motherboard
to A16 test set motherboard
➁
50R 8121-0817 1
A41 hard disk drive
to A15 CPU board
➂
4W 8121-0802 1
Front panel LED board J1
to A16 test set motherboard J502
➃
6W N5230-60015 1
USB hub board J3
to A14 system motherboard J20
➄
26R N5230-60012 1
A19 MASS 50 J30
to A16 test set motherboard J4
➅
16R N5230-60013 1
A20 mixer brick J1
to A16 test set motherboard J12
➆
24R N5230-60014 1
A18 MA 26.5 J1
to A16 test set motherboard J7
