6-36 Service Guide N5230-90024
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230C
Internal Hardware and Miscellaneous Parts, All Options
Reference
Designator
Part Number Qty Description
B1 3160-1085 3 Fan
➀
E8356-00027 1 Chassis assembly
➁
N5230-00001 1 Test set deck
➂
5022-1087 2 Test port coupler nut
➃
0515-1227 8
Machine screw, M3.0 x 6 flat head (to attach
➄
)
➄
E8362-00003 1
Test set deck front panel (For Option 220 analyzers with serial numbers
prefixed MY4500 and below and Option 225 analyzers.)
N5230-00010 1
Test set deck front panel (For Option 220 analyzers with serial numbers
prefixed MY4640 and above.)
E8364-00014
Test set deck front panel (For All Option 420, 425, 520, and 525
analyzers.)
➅
P/O RF cable 12
3.5 mm (f) bulkhead connectors (20 GHz models)
2.4 mm (f) bulkhead connectors (40 and 50 GHz models)
➆
P/O RF cable 12
Washer (for bulkhead connectors,
➅
)
➇
P/O RF cable 12
Hex nut (for bulkhead connectors,
➅
)
➈
E8356-40004 1 Line switch button
➉
1460-2632 1 Line switch spring
E4406-60109 1 Midweb assembly (includes three fans, B1)
E8364-00021 1 Clamp, ribbon cable
0515-0374 1
Machine screw M3.0 x 10, pan head (for cable clamp, item
)
11
12
13
12
