6-30 Service Guide N5230-90024
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230C
Bottom Cables, Options 425 and 525
Reference
Designator
Type
a
a. SR = semirigid coaxial cable; F = flexible coaxial cable; nR = n wires in a ribbon (flat) cable; nW = n wires in a wrapped cable
Part Number Qty Description
W3, W6 SR Refer to “Top Cables, All Options” on page 6-14.
W7 SR N5230-20033 1 A18 MA 26.5 to A19 MASS 50
W21-W24 F Refer to “Top Cables, All Options” on page 6-14.
W29 F N5230-60004 1 A19 MASS 50 J2 to A16 test set motherboard J205 (R2)
W30 F N5230-60003 1 A19 MASS 50 J1 to A16 test set motherboard J204 (R1)
W31 F N5230-60005 1 A19 MASS 50 J3 to A16 test set motherboard J206 (MASS)
W40 SR N5230-20030 1 A19 MASS 50 to A25 port 1 step attenuator
W41 SR N5230-20031 1 A19 MASS 50 to A26 port 2 step attenuator
W42 SR E8364-20053 1 A25 step attenuator to PORT 1 SOURCE OUT
W43 SR E8364-20054 1 A26 step attenuator to PORT 2 SOURCE OUT
W44 SR N5230-20047 1 PORT 1 CPLR THRU to A21 test port 1 coupler
W45 SR N5230-20048 1 PORT 2 CPLR THRU to A22 test port 2 coupler
W46 SR N5230-20036 1 A19 MASS 50 to REFERENCE 1 SOURCE OUT
W47 SR N5230-20038 1 A19 MASS 50 to REFERENCE 2 SOURCE OUT
W48 SR E8364-20043 1 PORT 1 CPLR ARM to A21 test port 1 coupler
W49 SR E8364-20044 1 PORT 2 CPLR ARM to A22 test port 2 coupler
W50 SR N5230-20035 1 PORT 1 RCVR A IN to A20 mixer brick (A)
W51 SR N5230-20037 1 REFERENCE 1 RCVR R1 IN to A20 mixer brick (R1)
W52 SR N5230-20039 1 REFERENCE 2 RCVR R2 IN to A20 mixer brick (R2))
W53 SR N5230-20032 1 PORT 2 RCVR B IN to A20 mixer brick (B)
W60 SR E8364-20059 6 Front panel jumper
➀
100R 8121-0118 1 A14 system motherboard to A16 test set motherboard
➁
50R 8121-0817 1 A41 hard disk drive to A15 CPU board
➂
4W 8121-0802 1 Front panel LED board J1 to A16 test set motherboard J502
➃
6W N5230-60015 1 USB hub board J3 to A14 system motherboard J2
➄
26R N5230-60012 1 A19 MASS 50 J30 to A16 test set motherboard J4
➅
16R N5230-60013 1 A20 mixer brick J1 to A16 test set motherboard J12
➆
24R N5230-60014 1 A18 MA 26.5 J1 to A16 test set motherboard J7
➇
10R 8121-0819 1 A25 step attenuator to A16 test set motherboard P510
➈
10R 8121-0119 1 A26 step attenuator to A16 test set motherboard P512
